Protection Aircraft Shelter (PAS) Automatic Gate
The Madoors USA Protection Aircraft Shelter Automatic Gate is a NATO-standard hardened explosion gate system engineered to protect F-16, F-35, and equivalent generation fighter aircraft from bombardment, blast overpressure, and shrapnel fragmentation — manufactured locally in compliance with NATO standards, independently burst pressure tested and certified, and globally accepted with full test report documentation. Built on a reinforced steel carcass clad with ballistic steel and filled with hardened silica-fume reinforced concrete blocks during final assembly, the Madoors USA PAS gate delivers the highest available protection for aircraft shelter doors — preventing explosion pressure and shrapnel fragments from penetrating the shelter interior even when the airfield is under active bombardment, ensuring that the aircraft inside remain undamaged and operational.
Available in electromechanical motor and hydraulic motor driven configurations, with all motors, electrical system panels, and hardware manufactured from Ex-proof materials in compliance with NATO standards, the Madoors USA PAS Automatic Gate carries a 2-year warranty and is supported by Madoors USA engineering for project specification, main frame engineering, and installation consultation.
TECHNICAL SPECIFICATIONS
The Madoors USA PAS gate is a sliding door system constructed on a reinforced steel carcass — providing the primary structural load-carrying frame that supports the ballistic steel cladding and concrete fill under the dynamic loading of blast overpressure and fragment impact. Hardened silica-fume reinforced concrete blocks are placed between the sliding steel carcasses during the final main frame assembly process — forming a composite ballistic and blast-resistant wall structure within the gate leaf that combines the ductile energy absorption of reinforced steel with the compressive strength and ballistic attenuation mass of hardened concrete.
Silica-fume concrete provides significantly higher compressive strength and density than standard concrete — with silica-fume pozzolanic reaction producing a denser, less permeable matrix that improves both blast pressure resistance and ballistic protection performance per unit of wall thickness compared to standard concrete mix designs. This enhanced concrete specification within the gate construction maximizes protection performance while minimizing gate weight for a given protection level.
Ballistic steel cladding on the reinforced steel carcass provides the primary fragment and projectile arrest layer — stopping the high-velocity shrapnel fragments generated by nearby bomb and missile detonations before they penetrate to the concrete fill layer and the aircraft interior beyond. The combined ballistic steel and hardened concrete composite wall achieves the protection against the combined blast and fragment threat posed by military bombardment scenarios.
All drive systems, electrical panels, and hardware are manufactured from Ex-proof materials compliant with NATO standards — ensuring that the gate drive and control systems remain operational in the explosive atmosphere that may be present at an active military airfield under bombardment, and satisfying the NATO procurement requirements for explosion-proof electrical classification of all components at military aircraft shelter installations.
Two drive system configurations cover different power infrastructure and operational requirements. Electromechanical motor drive provides reliable, electrically efficient automated gate operation for standard airfield power supply conditions. Hydraulic motor drive provides high-force output for the largest and heaviest gate configurations, consistent force delivery under temperature extremes, and operational reliability in the highest-demand military operational environments.
