Mobile Portable Tire Killer
The Madoors USA Mobile Portable Tyre Killer is a surface-mounted, no-excavation spike barrier system providing one of the highest security vehicle access control solutions available — deployable in 2 seconds on concrete and most asphalt road surfaces without any excavation or civil works, stopping vehicles in one button press, and providing effective one-directional traffic control enhanced by remote control capability. Available in three drive configurations — mechanical, electromechanical motorized, and hydraulic — and in rubber-type and steel-type mobile portable configurations, the Madoors USA Mobile Portable Tyre Killer is the ideal rapid-deployment spike barrier for banks, military bases, airports, embassies, and any high-security vehicle access point requiring immediate, relocatable tyre killer protection.
TECHNICAL SPECIFICATIONS
The Madoors USA surface-mounted tyre killer is installed directly on the roadway surface — no excavation, no foundation works, and no road surface cutting are required. The complete installation procedure is: place the tyre killer at the installation site, mark the floor through the holes on the base plate, set steel anchors at the marked positions, replace the tyre killer over the anchors, apply washers to the base plate, and secure. Total installation time is 2 seconds for the mobile portable configuration and minutes for the permanent surface-mount anchored configuration.
The special hardened steel teeth rise 60mm above the tyre killer top plate level in the deployed position — providing the penetration depth required for immediate, complete tyre wall destruction on unauthorized vehicle passage. Teeth are manufactured from 10mm steel plate and attached to a 16mm diameter hardened steel rod. Each tooth works individually in the mechanical configuration — lowering under the weight of an authorized vehicle's tyre passing over in the permitted direction and automatically returning to the raised position after the tyre passes. The full-length tooth measurement is 32cm, standing 10cm above ground level in the standard raised position.
The surface mount housing frame withstands 60 tons of axle load — confirming structural integrity for the heaviest commercial and military vehicles in both the authorized pass-over direction and under direct hostile vehicle impact. All main body components and teeth are hot-dip galvanized and epoxy coated to 60 micrometers thickness to prevent rusting in all outdoor exposure conditions. Teeth are painted red to attract driver attention — the tyre killer simultaneously functions as a speed bump visual warning device.
Three drive system types provide different performance and operational profiles. Mechanical type — individual teeth lower individually under vehicle weight in the authorized direction, automatically return to raised position after passage. No electrical power required. Latch Down Mechanism optionally locks all teeth in the lowered position simultaneously. Electromechanical motorized type — all teeth move together driven by the electromechanical drive unit mounted above ground level at one end of the tyre killer. Drive unit is above ground, complete assembly with the body, providing smooth motion transmission and minimum external factor effect. Hydraulic type — electro-hydraulic drive with 3-second standard raise/lower time and 1.5-second emergency response, manual hand pump backup for power failure, PLC control for integration with all access control interfaces.
KEY FEATURES
One-Button Instant Vehicle Stop — Remote Control
The portable tyre killer stops vehicles with a single button press — the battery-powered spike deployment system responds instantly to the remote control command, raising all spikes simultaneously to the deployed position. Remote control operation allows the security officer to stop vehicles at distance without physical proximity to the vehicle — directly protecting the officer from vehicle attack scenarios where the threat vehicle is the one being stopped.
2-Second Surface Installation — No Excavation
The 2-second mobile installation on concrete and asphalt surfaces without any excavation is the defining operational advantage of the portable tyre killer over all permanent installed systems — the unit is placed, anchors are set, and the barrier is operational within seconds of arrival at the deployment position. This rapid installation makes the mobile portable tyre killer the appropriate specification for any security application requiring immediate, temporary, or frequently relocated spike barrier protection.
Individual Tooth Operation — Mechanical One-Way Traffic
The individual tooth operation of the mechanical configuration provides the one-way traffic control principle — each tooth lowers individually under the vehicle tyre weight as an authorized vehicle passes over in the permitted direction, and returns automatically to the raised position after the tyre passes. A vehicle attempting to pass from the opposite direction encounters all teeth in the raised position — tyre destruction is immediate and complete. This passive mechanical operation requires no power, no control system, and no operator action for the basic one-way access control function.
60mm Tooth Height — Immediate Tyre Destruction
The 60mm tooth height above the top plate level provides the penetration depth required for immediate, complete destruction of all tyre types — passenger car tyres, light commercial tyres, and heavy goods vehicle tyres — on unauthorized passage. The hardened steel tooth material ensures that the tooth penetrates the tyre without tooth deformation or breakage under the impact of high-speed unauthorized vehicle approaches.
60-Ton Axle Load Resistance — All Vehicle Types
The 60-ton axle load resistance confirms structural integrity for the heaviest vehicles that will pass over the tyre killer in the authorized direction — including fully loaded articulated heavy goods vehicles, military vehicles, and construction plant. This load resistance ensures that the authorized vehicle pass-over function does not cause structural damage to the tyre killer mechanism even under repeated heavy axle loading.
Hot-Dip Galvanized & Epoxy Coated — Outdoor Durability
Hot-dip galvanization and epoxy coating to 60-micrometer thickness on all steel components — body, teeth, and mechanism — provides the corrosion resistance required for permanent outdoor installation in all weather and climate conditions. This coating system directly extends the service life of the outdoor-installed tyre killer without surface treatment maintenance throughout the operational deployment period.
Hydraulic Type — 3-Second Standard, 1.5-Second Emergency
The hydraulic type provides 3-second standard raise/lower cycle time for normal access control operation and 1.5-second emergency response for immediate threat deployment. Manual hand pump backup maintains barrier capability during power failure. PLC integration with card readers, biometric readers, loop detectors, photocells, traffic lights, and remote controls provides the full access control interface compatibility required for integration into any facility security management system.
Latch Down Mechanism — All Teeth Lock Simultaneously
The optional Latch Down Mechanism locks all mechanical tyre killer teeth simultaneously in the lowered position for extended authorized vehicle access periods — the mechanism is placed at one end of the tyre killer, stands below ground level, and is a complete assembly with the body. Manual drive of all teeth through the latch mechanism provides both individual tooth independent operation for normal directional control and simultaneous all-teeth lowering for controlled access periods.
PLC Control — Universal Access Control Integration
The hydraulic tyre killer PLC control integrates with all standard access control interfaces — allowing the spike barrier to be governed by the same card reader, biometric, loop detector, and remote control systems that manage all other access control devices at the checkpoint. This universal integration eliminates compatibility constraints and allows the tyre killer to be added to any existing access control infrastructure without requiring bespoke control system engineering.
PRODUCT RANGE
Mechanical Mobile Portable — Rubber type and steel type. Individual tooth operation. No power required. One-way directional control. Optional Latch Down Mechanism. 2-second installation. Remote control one-button stop. Battery-powered spike deployment.
Electromechanical Motorized — All teeth move together. Above-ground drive unit. Smooth motion transmission. Minimum external factor effect. Powered operation.
Hydraulic Surface Mount — 3-second standard, 1.5-second emergency. Manual hand pump backup. PLC control. Universal access control integration. 60-ton axle load. Hot-dip galvanized.
ASSEMBLY & INSTALLATION SEQUENCE
Deployment Position Selection
The tyre killer installation position is selected — aligned perpendicular to the vehicle approach direction. The authorized vehicle passage direction and unauthorized direction threat profile are confirmed.
Mobile Portable Installation — 2-Second Procedure
For mobile portable deployment: the tyre killer is placed at the installation position. Floor positions are marked through the base plate holes. Steel anchors are set at the marked positions. The tyre killer is replaced over the set anchors with washers on the base plate. The tyre killer is secured. Total installation time: 2 seconds to operational status.
Permanent Surface Mount Anchoring
For permanent surface mount installation: steel anchor bolts are set to the confirmed embedment depth at all marked positions. The tyre killer is secured to all anchors with nuts and washers to the confirmed torque.
Drive System Connection (Electromechanical & Hydraulic)
Electromechanical or hydraulic drive system is connected to the power supply and control system. PLC programming for the access control interface is completed.
Latch Down Mechanism & Access Control Integration
Optional Latch Down Mechanism is installed and tested for all-teeth simultaneous lowering and return. All access control devices are connected to the PLC and tested.
Operational Testing & Handover
Directional one-way operation, emergency response time, manual hand pump backup, and all access control interfaces are tested. Installation documentation is completed.
DEPLOYMENT SCENARIOS & USE CASES
Madoors USA Mobile Portable Tyre Killers are specified for any vehicle access control point requiring rapid-deployment, surface-mounted, one-way spike barrier protection.
- Bank and financial institution vehicle access control
- Military base vehicle entry directional tyre killers
- Airport ground vehicle access directional control
- Embassy and diplomatic compound vehicle barriers
- Prison and correctional facility vehicle entry control
- Government building vehicle access tyre killers
- Police station and courthouse vehicle access barriers
- Hospital and healthcare facility parking control
- Corporate headquarters and campus vehicle access
- Shopping center and retail park entry tyre killers
- Hotel and hospitality property vehicle access barriers
- Construction site temporary vehicle access control
- Event security temporary directional vehicle barriers
- Emergency checkpoint rapid-deployment tyre killers
- Any security application requiring immediate surface-mounted spike barrier deployment
