Bulletproof Automatic Roller Shutter Door, Bullet Resistant Motorized Shutter Window
The Madoors USA Bulletproof Automatic Roller Shutter Door and Bullet Resistant Motorized Shutter Window is a ballistic steel and aluminum roller shutter system manufactured to European BR3 through BR7 ballistic standards and American UL 752 Levels 1 through 9 — providing certified bullet-resistant protection for building windows, door openings, and access points across the complete range of handgun, assault rifle, and high-powered rifle threat levels. All ballistic steel used in the system is approved and reported by authorized certification institutions. Motor systems use Siemens brand side drive motors with Italian worm-geared reducers. Every system is designed and manufactured to customer-specified project dimensions and carries a 2-year company guarantee.
TECHNICAL SPECIFICATIONS
Madoors USA Bulletproof Roller Shutter systems are available in ballistic steel and aluminum construction types, manufactured to the following certified ballistic protection standards.
European EN 1063 standards: BR3 — protection against .44 Magnum handgun rounds. BR4 — protection against 9mm submachine gun fire. BR5 — protection against 5.56mm assault rifle rounds. BR6 — protection against 7.62mm × 39 assault rifle rounds. BR7 — protection against 7.62mm × 51 NATO rifle rounds — the highest standard level, providing protection against the most powerful military rifle calibers in operational use.
American UL 752 standards: Level 1 through Level 9 — covering the complete range from 9mm handgun protection at Level 1 through to 7.62mm rifle protection at Level 8 and beyond at Level 9. Ballistic reports are provided for all certified levels between UL 752 Level 1 and Level 9, with intermediate levels including Level 3 for .44 Magnum, Level 5 for 7.62mm rifle, and Level 8 for sustained 7.62mm rifle fire all covered within the manufacturing capability range.
The shutter operates by turning and wrapping the ballistic steel or aluminum curtain onto the overhead drum on opening, and unwinding from the drum on closing — maintaining the ballistic integrity of the curtain throughout the full open and close travel cycle without mechanical joints, overlapping sections, or gap formations in the protection layer at any position in the travel. Motor drive uses Siemens brand side drive motors providing reliable, commercial-grade automated operation. Reducers are Italian worm-geared type, providing smooth, controlled drum rotation with the torque reduction required for heavy ballistic steel curtain weight management.
All systems are designed and manufactured to customer-specified project dimensions — with no standard size limitation — ensuring precise fit to any building window, door, or opening geometry without requiring structural modification of the surrounding wall or frame.
KEY FEATURES
BR3 to BR7 European Ballistic Certification
The full range of EN 1063 European ballistic protection levels from BR3 through BR7 is available within the Madoors USA bulletproof roller shutter manufacturing capability — providing certified protection against the complete spectrum of handgun, submachine gun, and military rifle threats from .44 Magnum through to 7.62mm × 51 NATO rounds. European EN 1063 certification satisfies government, institutional, and commercial security procurement specifications across all European and internationally aligned markets.
UL 752 Level 1 to Level 9 American Certification
The complete American UL 752 bullet resistance rating range from Level 1 through Level 9 is available, with ballistic test reports provided for certified performance at all intermediate levels between Level 1 and Level 9. UL 752 certification satisfies US government, banking, financial institution, and commercial security procurement specifications for certified bullet-resistant shutter and window systems across the North American market and internationally where UL certification is specified.
Ballistic Steel & Aluminum Construction Options
Two construction material options are available — ballistic steel and ballistic aluminum — providing selection flexibility based on the required protection level, weight constraints, corrosion resistance requirements, and aesthetic specifications of each project. Ballistic steel construction provides the highest protection-to-thickness ratio for the highest ballistic levels. Ballistic aluminum construction provides reduced weight for applications where curtain weight and drum load are constrained by the building structure or motor specification.
Authorized Institution Certification & Ballistic Reports
All ballistic steel and aluminum materials used in Madoors USA bulletproof roller shutters are approved and reported by authorized certification institutions, with ballistic test reports available for each protection level. These independently issued reports provide clients with verified ballistic performance documentation for procurement compliance, insurance, and security specification purposes — confirming that the protection level claimed is independently substantiated by real ballistic testing rather than manufacturer assertion alone.
Siemens Side Drive Motor — Proven Commercial Reliability
The Siemens brand side drive motor provides reliable, long-service-life automated operation with the commercial-grade performance of Siemens industrial motor technology — the same proven motor platform used across the Madoors USA automated door and shutter product range. Siemens motor specification provides clients with confidence in motor performance longevity and global availability of replacement parts and service support.
Italian Worm-Geared Reducers
Worm-geared Italian type reducers provide the high torque reduction ratio required for smooth, controlled rotation of heavy ballistic steel shutter curtains on the drum — preventing uncontrolled curtain speed during descent under gravity and maintaining consistent, smooth motor-controlled movement throughout the full travel range of heavy protection-level ballistic steel curtains.
Drum Wrap Operation — Continuous Ballistic Integrity
The drum-wrap shutter mechanism maintains the full ballistic integrity of the curtain throughout the complete open and close travel cycle — with the curtain wrapping continuously onto the drum without mechanical joints, lapping sections, or gaps forming in the protection layer at any travel position. This continuous integrity is the fundamental ballistic performance advantage of the drum-wrap roller shutter format over sliding panel and folding shutter systems where panel joints and overlaps create potential penetration paths.
Custom Project Dimensions — Any Opening Size
Every Madoors USA bulletproof roller shutter system is designed and manufactured to the customer's project-specific dimensions — covering any building window width and height, any door opening dimension, and any non-standard aperture geometry. Custom sizing ensures a precise fit without requiring structural modification of the surrounding opening or compromise in ballistic protection coverage at panel edges.
2-Year Company Guarantee
All Madoors USA bulletproof roller shutter door and motorized shutter window systems carry a 2-year company guarantee, providing client assurance of system performance and manufacturing quality across the initial operational service period.
BALLISTIC PROTECTION LEVEL GUIDE
BR3 / UL 752 Level 3 — .44 Magnum revolver, 3 shots. Suited to retail security, commercial building window protection, and light security applications where handgun threats are the primary concern.
BR4 / UL 752 Level 4 — 9mm submachine gun and .30 caliber rifle. Suited to financial institutions, government building windows, and commercial security applications requiring enhanced handgun and entry-level rifle protection.
BR5 / UL 752 Level 5 — 5.56mm assault rifle. Suited to government facilities, police stations, and security-critical commercial buildings where assault rifle threats must be addressed.
BR6 / UL 752 Level 6 — 7.62mm × 39 assault rifle rounds. Suited to military support facilities, government buildings in high-threat environments, and embassy auxiliary building protection.
BR7 / UL 752 Level 8 — 7.62mm × 51 NATO rifle rounds. The highest standard protection level — suited to military facilities, embassy principal buildings, government high-security installations, and critical infrastructure control rooms where military rifle threats are the governing ballistic design parameter.
UL 752 Level 9 — the highest American standard rating, covering sustained high-powered rifle fire beyond Level 8 specification. Suited to the most demanding military and government high-security applications.
ASSEMBLY & INSTALLATION SEQUENCE
Opening Measurement & Project Specification
All opening dimensions — width, height, and reveal depth — are measured for each installation location. Ballistic protection level is confirmed — BR3 through BR7 or UL 752 Level 1 through 9. Construction material — ballistic steel or aluminum — is selected based on protection level and weight requirements. Motor specification and reducer type are confirmed for the specific curtain weight and duty cycle.
Custom Manufacturing
The ballistic steel or aluminum shutter curtain, drum assembly, side guides, and motor housing are manufactured to the confirmed project dimensions and protection level specification. Ballistic test report for the specified protection level is prepared and verified.
Structural Opening Preparation
The structural opening is prepared for shutter installation. Header clearance for the drum housing is verified. Side guide channel positions are marked and fixing positions are prepared. Motor power supply routing is confirmed.
Drum Housing & Motor Installation
The drum housing containing the Siemens side drive motor and Italian worm-geared reducer is installed at the header position above the opening. Motor electrical connections are made and verified. Drum alignment and rotation are tested before curtain installation.
Side Guide Channel Installation
Ballistic steel side guide channels are installed on both sides of the opening and secured to the surrounding structure. Guide channel alignment, plumb, and parallel spacing are verified across the full curtain travel height.
Ballistic Curtain Installation & Drum Loading
The ballistic steel or aluminum curtain is loaded onto the drum and threaded into the side guide channels. Curtain travel, guide channel contact, and drum wrap geometry are verified across the full open and close travel range.
Motor Commissioning & Travel Limit Setting
Open and close travel limits are set and verified. Motor speed and deceleration are adjusted for the specific curtain weight and ballistic steel construction. Remote control, switch control, and any access control interface connections are tested.
Ballistic Report & Certification Documentation Handover
Authorized institution ballistic test reports for the installed protection level — EN 1063 BR rating and UL 752 level as applicable — are compiled into the project handover package alongside installation records and the 2-year guarantee documentation.
DEPLOYMENT SCENARIOS & USE CASES
Madoors USA Bulletproof Automatic Roller Shutter Doors and Bullet Resistant Motorized Shutter Windows are specified for any building opening requiring automated, motorized ballistic protection at certified BR3 to BR7 or UL 752 Level 1 to 9 performance levels.
- Bank branch and financial institution teller window protection
- Currency exchange and cash handling facility shutter systems
- Government building and ministry window ballistic protection
- Embassy and diplomatic facility window and door shutters
- Military base administrative building window protection
- Police station and law enforcement facility window shutters
- Prison and correctional facility window ballistic protection
- Jewelry retail and high-value goods store security shutters
- Pharmacy and dispensary window protection systems
- Airport security checkpoint and restricted area shutters
- Hotel and hospitality facility high-security window protection
- Corporate headquarters and premium office ballistic shutters
- Critical infrastructure control room window protection
- Court complex and justice facility window ballistic shutters
- VIP residence and protected compound window shutter systems
