Automatic Folding Gate
The Madoors USA Automatic Folding Gate system is a motorized swing gate and folding gate solution engineered to improve property security, protect privacy, and prevent unauthorized access across residential, commercial, and industrial applications. Available with multiple motor types and drive configurations — including heavy-duty pivot motors for large and heavy gate leaves, above-ground articulated arm operators for installations with large or obstructing gate pillars, and underground electro-mechanical or hydraulic operators for clean aesthetic installations — the Madoors USA automatic folding gate system is configurable to meet the specific gate weight, opening width, pillar geometry, and operational requirements of any installation.
TECHNICAL SPECIFICATIONS
Madoors USA automatic folding and swing gate systems are available with motor and drive configurations matched to the specific gate weight, leaf length, operational cycle rate, and installation geometry of each project. Motor selection is determined by gate weight and leaf span — lighter residential gates are served by light-duty domestic motors, while heavier commercial and industrial gate leaves require heavy-duty motors with the torque output to reliably open and close larger gate masses across high daily cycle rates.
Three primary motor and drive configurations are available. Pivot post-mounted motors are attached directly to the gate posts and operate by pivoting to pull the gate leaf open and push it closed. This configuration requires strong, structurally robust gate posts capable of carrying the cantilever load of the gate leaf weight without leaning or deflecting under the lateral forces generated by the motor pivot action during gate operation. Above-ground articulated arm operators are installed with a hinged arm that reaches around the gate pillar to connect the motor unit to the gate leaf — providing a functional motor installation solution for gates where the pillar geometry or size prevents direct pivot motor attachment. Underground gate operators — available in electro-mechanical and hydraulic versions — are installed into the ground beneath the gate hinge position, with a hinge mechanism that pivots the gate leaf open and closed from below ground level, providing the cleanest possible aesthetic installation with no visible motor hardware above the gate or pillar surface.
KEY FEATURES
Heavy-Duty Motors for Large & Heavy Gates
Heavier and longer gate leaves require heavy-duty motors with sufficient torque output to reliably move the gate mass across the full open and close travel range at the specified operational cycle rate. Madoors USA heavy-duty swing gate motors are rated for the gate weight and leaf span of commercial and industrial gate installations, providing consistent, reliable operation under the demanding cycle rates of active commercial and industrial property entrances.
Light-Duty Motors for Residential Applications
For standard residential swing gates where gate weight and leaf span fall within domestic motor ratings, light-duty gate motors provide reliable, cost-effective automatic gate operation suited to the lower cycle rates and gate weights of residential property entrances — without the over-specification and associated cost of commercial-grade heavy-duty motor systems.
Pivot Post-Mounted Motor Configuration
The pivot post-mounted motor is attached to the gate post and operates by pivoting to pull the gate leaf open and push it closed through the full open and close travel arc. This is the most widely used swing gate motor configuration, providing a straightforward mechanical connection between the motor unit and the gate leaf. Strong, rigid gate posts are essential for this configuration — posts that flex or lean under gate leaf weight will compromise motor alignment and gate operation over time.
Above-Ground Articulated Arm Operator
The above-ground articulated arm operator is the preferred solution for gate installations where the gate pillar size, shape, or surface geometry prevents direct pivot motor attachment. The hinged arm is installed to reach around the pillar and connect the motor unit to the gate leaf, providing a functional and reliable motor installation across the full range of pillar configurations that would otherwise prevent automated gate operation. The articulated arm configuration is compatible with most gate installation types and is a practical universal solution where other motor types cannot be used.
Underground Electro-Mechanical Operator
The underground electro-mechanical gate operator is installed into the ground beneath the gate hinge position, completely concealing the motor hardware below ground level. The pivot mechanism operates the gate leaf from the underground position, with no visible motor hardware above the gate or pillar surface — delivering the cleanest possible aesthetic installation for premium residential, heritage, and architectural gate installations where surface-mounted hardware would compromise the visual character of the entrance.
Underground Hydraulic Operator
The underground hydraulic gate operator provides the same below-ground installation aesthetic as the electro-mechanical underground variant, with hydraulic drive delivering higher force output for heavier gate leaves and higher operational cycle rates than electro-mechanical underground motors can accommodate. The hydraulic underground operator is the preferred specification for heavy premium gates requiring underground installation — combining the clean aesthetic of concealed hardware with the high-torque performance of hydraulic drive.
Safety, Privacy & Security
Automatic swing gate motor systems directly improve property security by ensuring the gate closes fully and securely after each vehicle or pedestrian pass — eliminating the gap in perimeter security created by manually operated gates that are frequently left open after use. Automated closure protects privacy and prevents unauthorized pedestrian and vehicle access to the property throughout operational and non-operational hours.
MOTOR SELECTION GUIDE
Gate weight and leaf span are the primary parameters determining motor specification. The following general guidance applies to Madoors USA automatic swing gate motor selection.
Residential light-duty applications — standard domestic gate leaves of moderate weight and span — are served by light-duty domestic swing gate motors providing reliable automated operation at residential cycle rates.
Commercial and industrial applications — heavier gate leaves, longer spans, and higher daily cycle rates — require heavy-duty swing gate motors with the torque output, duty cycle rating, and service life to perform reliably under sustained commercial operational demands.
Large pillar or obstructed pillar installations — where pivot motor attachment to the gate post is prevented by pillar size or geometry — are served by above-ground articulated arm operators that reach around the pillar to connect the motor to the gate leaf.
Premium residential, heritage, and architectural installations — where concealed motor hardware is required for aesthetic reasons — are served by underground electro-mechanical or hydraulic operators providing fully hidden drive systems with no above-ground motor hardware visible at the gate or pillar.
ASSEMBLY & INSTALLATION SEQUENCE
Site Assessment & Motor Configuration Selection
Gate leaf weight, span, hinge geometry, pillar size and condition, available power supply, and operational cycle rate requirements are assessed. Motor type — pivot post-mounted, articulated arm, or underground electro-mechanical or hydraulic — is selected based on gate weight, pillar geometry, aesthetic requirements, and operational specification. Post structural integrity is assessed for pivot motor installations.
Gate Post & Foundation Verification
For pivot post-mounted motor configurations, gate post structural integrity and foundation anchorage are verified to confirm that the post can carry the combined weight of the gate leaf and the lateral forces generated by pivot motor operation without leaning or deflecting. Post reinforcement or replacement is completed where required before motor installation proceeds.
Underground Chamber Installation (Underground Operators)
For underground electro-mechanical and hydraulic operators, the underground chamber is excavated at the specified position beneath the gate hinge point. The operator chamber is installed, waterproofed, and connected to the electrical or hydraulic supply. The pivot mechanism is positioned and aligned for correct gate leaf connection geometry.
Motor Unit Installation & Gate Leaf Connection
The selected motor unit is installed at the specified mounting position — post-mounted, articulated arm bracket, or underground chamber. The motor connection to the gate leaf is made through the pivot arm, articulated arm, or underground pivot mechanism. Gate leaf swing geometry, motor travel limits, and connection hardware torque are verified.
Electrical Supply & Control System Connection
The motor unit is connected to the facility electrical supply. The control system — including remote control receivers, keypad, intercom, card reader, or other access control interface as specified — is installed and connected. Safety system connections — photocell beams, safety edges, and loop detectors — are installed and wired.
Limit Setting & Speed Commissionin
Gate open and close limit positions are set and verified for correct full-open and fully-closed positions. Motor speed, deceleration, and obstacle detection sensitivity are adjusted for the specific gate weight and installation geometry. Remote control and access control system operation are tested across all programmed functions.
Safety System Testing & Final Handover
All safety systems — obstruction detection, auto-reverse, photocell beam, and emergency stop — are tested and verified. Complete operational testing is conducted across all remote control, access control, and manual release functions. Installation handover documentation is completed.
DEPLOYMENT SCENARIOS & USE CASES
Madoors USA Automatic Folding and Swing Gate systems are specified across the full range of residential, commercial, and industrial property entrance applications.
- Residential driveway and property entrance swing gates
- Villa and private estate entrance automated gates
- Residential community and gated development entrance gates
- Commercial premises and office building vehicle entrance gates
- Industrial facility and warehouse property entrance gates
- Agricultural and rural property entrance automated gates
- School and educational campus vehicle entrance gates
- Hotel and hospitality property vehicle entrance gates
- Healthcare facility and hospital vehicle entrance control
- Government building and institutional property entrance gates
- Parking facility entrance and exit automated swing gates
- Heritage and architectural property concealed underground operator gates
