Aluminium Rolling Shutter
The Madoors USA Aluminium Rolling Shutter is an automatic and manual aluminum roller shutter system for doors, gates, and windows — engineered for residential, villa, garage, and commercial building applications where architectural aesthetics, functional ventilation control, light management, security, and long-term durability are all primary requirements. Available in motorized automatic and manual operation variants, the system is suitable for single or multiple casement windows and door entrances, extremely easy to install, and fully customizable in any RAL color, wood pattern finish, or project-specific dimension.
Throughout the history of modern architecture, aluminum roller shutter systems have added measurable aesthetic value to building facades while delivering practical functionality in light control, ventilation, privacy, and weather protection. The Madoors USA aluminium rolling shutter combines these qualities in a double-walled extruded aluminum profile system with full 180-degree lamella rotation, gasket-sealed darkness, and electrostatic powder paint finishing — built for long service life with minimal maintenance requirements.
TECHNICAL SPECIFICATIONS
Madoors USA Aluminium Rolling Shutters are manufactured from extruded double-walled aluminum profiles. Each profile forming the shutter body is drop-shaped in cross-section and operates within special plastic lamella adapters fixed with hair screws. The plastic lamella adapters are frictionless and resistant to all forms of wear and mechanical stress from repeated rotation cycles, ensuring smooth lamella movement throughout the service life of the system.
Each shutter lamella is capable of a full 180-degree rotation in both directions through special adapter accessories, providing complete control over ventilation airflow and light admission at any angle from fully open to fully closed. When the lamellas are rotated to the closed position, plastic gaskets connecting adjacent lamellas in both directions create a light-tight seal, providing complete darkness and full weather protection without light leakage between slats.
In the manual configuration, the shutter is controlled by hand using special plastic accessories designed for opening, closing, and adjusting lamella rotation angle — requiring no tools and no motorized drive components. In the automatic motorized configuration, the drive system allows remote or switch-controlled operation of shutter travel and lamella angle adjustment.
Wing locking accessories are available to fix shutter wings in position and prevent wind-induced movement or collision against the surrounding frame structure. All aluminum components are finished using electrostatic powder paint application in any RAL color code, with a wood pattern surface finish option available for installations where a natural timber aesthetic is preferred. Custom dimensions are available for any opening size.
KEY FEATURES
Double-Walled Extruded Aluminum Profiles
Shutter lamellas are manufactured from extruded double-walled aluminum profiles, providing structural rigidity, thermal insulation performance, and impact resistance superior to single-walled alternatives — while maintaining the low weight characteristic of aluminum that is essential for smooth manual and motorized operation.
Full 180-Degree Lamella Rotation
Each lamella rotates a full 180 degrees in both directions through special plastic adapter accessories, giving the user complete control over ventilation, light admission, and privacy at any angle. No other shutter system configuration provides this level of continuous adjustment between fully open ventilation and fully closed darkness.
Complete Darkness When Closed
When lamellas are rotated to the closed position, plastic gaskets connecting adjacent slats in both directions create a fully light-tight seal — providing complete darkness suitable for bedrooms, home cinemas, shift workers, and any space where full blackout performance is a requirement.
Frictionless Plastic Lamella Adapters
Lamella adapters are manufactured from frictionless plastic material resistant to all forms of tooth wear and mechanical stress, ensuring smooth, effortless lamella rotation with no binding or resistance throughout the full service life of the system — with no lubrication or maintenance required.
Easy Two-Direction Cleaning
Because the lamellas rotate fully in both directions, cleaning the shutter surface is straightforward from either face of the installation — eliminating the access limitations of fixed or single-direction shutter systems and reducing cleaning time and effort significantly.
Automatic & Manual Operation
The system is available in motorized automatic and manual operation variants. Motorized systems allow remote or switch-controlled operation of shutter travel and lamella angle, suited to applications where convenience, accessibility compliance, or multiple shutter coordination is required. Manual systems deliver reliable, maintenance-free operation through simple hand-operated plastic control accessories.
Wind-Resistant Wing Locking
Special locking accessories are available to fix shutter wings in position against wind-induced movement and collision with the surrounding frame — preventing noise, vibration, and potential damage in exposed outdoor installations subject to strong or sustained wind conditions.
Any RAL Color — Electrostatic Powder Paint
All aluminum shutter components are finished using electrostatic powder paint application, providing a durable, fade-resistant color finish in any RAL code color. The electrostatic application process ensures full surface coverage and adhesion superior to conventional spray painting — delivering long-term color stability in outdoor exposed conditions.
Wood Pattern Surface Finish
A wood pattern surface finish is available as an alternative to solid RAL color finishes, providing the aesthetic warmth and visual character of natural timber with the structural performance, weather resistance, and low maintenance requirements of aluminum construction.
Any Size — Fully Custom Dimensions
The shutter system can be produced in any size to fit any door or window opening dimension, with no standard size limitations. Custom dimensioning ensures a precise fit to the specific opening without requiring structural modification of the surrounding frame or wall.
Long Lifespan — Minimal Maintenance
All system components are manufactured for long-term durability and resistance to all external environmental factors. The frictionless lamella adapter system and durable aluminum profile construction eliminate the primary wear mechanisms of conventional shutter systems, delivering long service life with minimal maintenance requirements beyond routine cleaning.
Versatile Application — Doors, Windows & Gates
The system is equally suited to residential house and villa window installations, garage entrance doors, commercial building door entrances, and gate applications — providing a consistent architectural solution across all opening types within a single property or development.
ASSEMBLY & INSTALLATION SEQUENCE
Opening Measurement & Custom Fabrication
All opening dimensions — width, height, and reveal depth — are measured for each installation location. Shutter profiles, guide channels, and roller box housing are fabricated to the exact dimensions of each opening. RAL color or wood pattern finish is applied by electrostatic powder paint process during fabrication.
Guide Channel Installation
Aluminum guide channels are installed vertically on both sides of the opening, secured to the surrounding wall or frame structure. Channels are verified for plumb alignment and parallel spacing across the full height of the opening to ensure smooth shutter travel without binding.
Roller Box Housing Installation
The roller box housing — containing the shutter barrel, spring or motorized drive system, and wiring for motorized variants — is installed at the head of the opening above the guide channels. The housing is secured to the lintel or surrounding structure and verified for level alignment.
Shutter Curtain Assembly & Hanging
The assembled shutter curtain — formed from the interconnected double-walled drop-profile aluminum lamellas with plastic gasket connections — is inserted into the guide channels and attached to the roller barrel within the housing. Lamella adapter function and rotation movement are verified across the full 180-degree travel range.
Motorized Drive System Connection (Motorized Variants)
The motor unit within the roller box housing is connected to the facility electrical supply. Remote control or switch control operation is configured and tested. Limit positions for full open and full close travel are set and verified.
Locking Accessory Installation
Wind-resistant wing locking accessories are fitted where specified. Lock operation — engagement and release — is verified across all installed locking points.
Final Testing & Handover
Full operational testing is conducted across open, close, lamella rotation, locking, and — for motorized systems — remote control functions. Cleaning access from both faces is verified. Installation handover is completed with operating instructions for lamella angle adjustment and maintenance guidance.
DEPLOYMENT SCENARIOS & USE CASES
Madoors USA Aluminium Rolling Shutters are specified across a wide range of residential and commercial building applications where light control, ventilation management, privacy, security, and architectural aesthetics are required.
- Residential house and apartment window shutters
- Villa and private residence facade shutters
- Garage entrance door shutter systems
- Ground floor residential door entrance shutters
- Commercial shopfront window and door shutters
- Office building window shutter systems
- Hotel and resort room window shutters
- Restaurant and hospitality venue facade shutters
- School and institutional building window protection
- Warehouse and industrial unit door shutters
- Medical facility and cleanroom light-control shutters
- Retail store security shutter systems
